This document was generated on 04/02/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
51347-0200
Active
3.30mm Pitch Wire-to-Wire Receptacle Housing, Positive Lock, Single Row, 2 Circuits,
White
Documents:
3D Model
Drawing (PDF)
Product Specification PS-51284-002 (PDF)
RoHS Certificate of Compliance (PDF)
Product Specification PS-51284-001 (PDF)
Series
General
Product Family
Crimp Housings
image - Reference only
Series
Application
Product Name
UPC
51347
Signal, Wire-to-Wire
N/A
800756598970
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
China RoHS
Contains SVHC: No
Physical
Low-Halogen Status
Circuits (maximum)
Color - Resin
Gender
Glow-Wire Compliant
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Polarized to Mating Part
Stackable
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
2
Natural
Female
No
Yes
Nylon
500.000/mg
1
Bag
No
3.30mm
Yes
No
-25°C to +85°C
4A
PS-51284-001, PS-51284-002, RPS-51284-003,
RPS-51284-004, RPS-51284-006, RPS-51284-007,
RPS-51284-008, RPS-51284-009, RPS-51284-011,
RPS-51284-014, RPS-51347-002, RPS-51347-003
SD-51347-001, SD-51347-002
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
51347Series
Mates With
51346-0200
Use With
51348 , 56187
This document was generated on 04/02/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
